的主要用途与简洁/Brief Introduction：

全自己齿轮泵式膏体酱装罐线机这是总部融入餐饮市场需要联合开发的新产品研发设备。该选果机适用SUS304不銹钢齿轮泵式计量检验泵制定装罐线，且集自己上盖、自己旋盖、汽车电器不间断为集成，成本选用，征地赔偿户型小，诸多普遍使用于药厂、调味品、农药杀菌剂、热、化状品等行业中的溶剂木箱，适用GMP标准的标准。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

作用/characteristic：

◆主要包括齿轮泵式剂量泵执行工作灌装生产线，适宜繁多稠状度透明液体，要求高；泵的构成主要包括快接式拆下企业，更好地洗涤、清洗。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆注塞泵式计量检定泵连杆环金属金属金属材质只能根据行业内及粘液化学物质的有差异 选取硅天然橡胶，四氟乙稀或各种金属金属金属材质，独特场所选取工业陶瓷金属金属金属材质。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC的控制自功控制系统，调频可控硅调压，自功化的程度高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不灌装设备，系统自动计算模块。Lack of bottle filling, automatic counting function◆装量修改不方便，可以次修改所有的记量泵的充填量，也可对各级记量泵实现微幅修改；操作方法简约，修改最快。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆包装针头不设防滴漏问题装备，充填时前往瓶底包装，慢慢攀升，处理利用气泡。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆整套装置可不适用区别规格参数的可乐瓶，修改简易，可在暂时性间内实现。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆服务器按GMP特殊要求设计。The machine designed according to the requirements of GMP

高性能指标指标/technic parameter：

选用瓶里金桥铜业跨接线的截面积大小Size of bottles	20-1000ml（会按照标准要求订作）20-1000 - ml (according to your need）
适用于瓶里厚度Apply the bottle diameter	¢20-¢150mm
适用于盖子标准Apply the lid specifications	¢20-¢70mm
研发效果 production capacity	四头灌装生产线：1000-2500瓶/半小时 Four filling head: 1000-2500 bottles per hour 八头灌装设备：2500-4000瓶/h Eight head filling: 2500-4000 bottles per hour 12头罐装：4000-6000瓶/小时内 12 head filling: 4000-6000 bottles per hour
装量粗差The load error	±1%
旋盖合适率Screw cover percent of pass	≥99%
供电power supply	380V，50HZ
工作功率power	3.0KW
汽源gas sources	0.4-0.75MPA
加速度操控speed control	交流变频变速variable speed
